Raspberry Pi Pico Board RP2040 Chip High Performance Low Power Dual-core ARM Cortex M0+ Processor
SKU: MB1043
Availability:
In stock
Raspberry Pi Pico Board RP2040 in sri lanka
රු1,890.00 රු1,990.00 or 3 X රු630.00 with
In stock
Raspberry Pi Pico Board RP2040 Chip High-Performance Low Power Dual-core ARM Cortex M0+ Processor Flexible Microcontroller
Specification
21 mm × 51 mm form factor
RP2040 microcontroller chip designed by Raspberry Pi in the UK
Dual-core Arm Cortex-M0+ processor, flexible clock running up to 133 MHz
264KB on-chip SRAM
2MB onboard QSPI Flash
26 multifunction GPIO pins, including 3 analog inputs
2 × UART, 2 × SPI controllers, 2 × I2C controllers, 16 × PWM channels
1 × USB 1.1 controller and PHY, with host and device support
8 × Programmable I/O (PIO) state machines for custom peripheral support
Supported input power 1.8–5.5V DC
Operating temperature -20°C to +85°C
The castellated module allows soldering directly to carrier boards
Drag-and-drop programming using mass storage over USB
Low-power sleep and dormant modes
Accurate on-chip clock
Temperature sensor
Accelerated integer and floating-point libraries on-chip
Documentation
Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller:
Raspberry Pi Pico Datasheet
An RP2040-based microcontroller board
RP2040 Datasheet
A microcontroller by Raspberry Pi
Hardware design with RP2040
Using RP2040 microcontrollers to build boards and products
Getting started with Raspberry Pi Pico
C/C++ development with Raspberry Pi Pico and other RP2040-based microcontroller boards
Raspberry Pi Pico C/C++ SDK
Libraries and tools for C/C++ development on RP2040 microcontrollers
Raspberry Pi Pico Python SDK
A MicroPython environment for RP2040 microcontrollers
The API level Doxygen documentation for the Raspberry Pi Pico C/C++ SDK is available as a micro-site.
