Water Sensors
Showing 1–25 of 28 results
-
Presser Sensors, Sensors, Show All Sensors, Water Sensors
0 – 0.5Mpa Pressure Sensor G1/4 DC 5V For Oil Fuel Gas Water Air
Presser Sensors, Sensors, Show All Sensors, Water Sensors0 – 0.5Mpa Pressure Sensor G1/4 DC 5V For Oil Fuel Gas Water Air
Suitable for wall hanging furnace, gas furnace, gas storage, etc all kinds of hydraulic, pneumatic pressure measurement
2. Suitable for civil use product batch
3. Static accuracy: plus or minus 1.0% FS
4. Pressure range 0-0.5 MPa (can be customized according to customer requirements)
5. Wide range of temperature compensation
6. Medium for non-corrosive gas, water, oil, etc
SKU: SEN1548 -
Presser Sensors, Sensors, Show All Sensors, Water Sensors
0-10Mpa Pressure Sensor G1/4 DC 5V For Oil Fuel Gas Water Air
Presser Sensors, Sensors, Show All Sensors, Water Sensors0-10Mpa Pressure Sensor G1/4 DC 5V For Oil Fuel Gas Water Air
Description:
– Working Voltage: 5VDC
– Output Voltage: 0.5-4.5 VDC
– Sensor material: Carbon steel alloy
– Working Current: <=10 mA
– Working Pressure Range: 0-1.2 MPa
– Cable length: 17cm / 6.69inch
– Sensor Length: Approx. 5.1cm / 2.01inch
– Screw Diameter: 1.3cm / 0.51inch
SKU: SEN1641 -
Sensors, Show All Sensors, Water Sensors
Analog TDS Water Conductivity Sensor for Liquid Detection Water Quality Monitoring Module *Original
Sensors, Show All Sensors, Water SensorsAnalog TDS Water Conductivity Sensor for Liquid Detection Water Quality Monitoring Module *Original
This equipment can be used for the measurement of general household water quality.
Generally, the tap water TDS is within 100 (about 90 in Shenzhen) and the purified water is within 10.
The compatible TDS sensor is used to measure the TDS value of water. The TDS value can reflect the cleanliness of water and can be applied to water quality testing in the fields of domestic water and hydroponics.
TDS (Total Dissolved Solids): Indicates how many milligrams of dissolved solids are dissolved in 1 liter of water. In general, the higher the TDS value, the more lysate is contained in the water and the more unclean the water. Therefore, the size of the TDS can be used as one of the basis for reflecting the cleanliness of the water.
SKU: SEN1580 -
Sensors, Show All Sensors, Water Flow Sensors, Water Sensors
G1/2″ Water Flow Hall Sensor Switch Flow Meter 1-25L/min
Sensors, Show All Sensors, Water Flow Sensors, Water SensorsG1/2″ Water Flow Hall Sensor Switch Flow Meter 1-25L/min
Model:YF-B1
Rated Voltage:DC 5V
Working Range:1-25L/min
Water Pressure:1.75MPa
Operating Voltage Range:DC 5-15V
Insulation Resistance:>100M ohm
Output Pulse Duty Cycle:50%+/-10%
Size: about 4.4cmx1.9cm
[Conversion: 1cm=0.3937 inch, 1inch=2.54 cm]
SKU: SEN1561 -
Sensors, Show All Sensors, Water Sensors
Liquid PH Value Detection detect Sensor Module Monitoring Control For Arduino
Sensors, Show All Sensors, Water SensorsLiquid PH Value Detection detect Sensor Module Monitoring Control For Arduino
The PH sensor module is a cheap and easy-to-use pH meter detection sensor module. This sensor module can be an analog pH meter designed for Arduino, single-chip and other controllers. It has the characteristics of simple connection, convenience and practicality.
Onboard power indicator, BNC interface and PH2.0 interface
When in use, connect the pH sensor to the onboard BNC interface, and connect the onboard PH2.0 interface to the analog port of the Arduino controller. Through program control, you can measure the pH value of the solution very conveniently.
The sensor’s electrode adopts a plastic non-fillable composite electrode that is a combination of a glass electrode and a reference electrode. It is a measuring element of a pH meter and is used to measure the activity of hydrogen ions in an aqueous solution, that is, the pH value.
SKU: SEN1614 -
Sensors, Show All Sensors, Water Flow Sensors, Water Sensors
Magnetic Flow Meter SEN-HZ21WA Miniature Water Sensor Hall Effect Pulse Signal
Sensors, Show All Sensors, Water Flow Sensors, Water SensorsMagnetic Flow Meter SEN-HZ21WA Miniature Water Sensor Hall Effect Pulse Signal
Product Name Miniature nylon flowmeter, turbine flow sensor
Material Nylon PA 66 material
Connection Size 1/2″, DN15
Flow Range 0.5-20 L/Min, 1-30 L/Min
Contact Capacity DC 5-24V can be customized DC 3V
Function
Measure water flows, It is installed in various coffee machines, water dispensers, and water inlets of electrolyzers to detect the influent flow.
SKU: SEN1657 -
Sensors, Show All Sensors, Water Flow Sensors, Water Sensors
Magnetic Plastic Water Flow Sensor Switch G1/2
Sensors, Show All Sensors, Water Flow Sensors, Water SensorsMagnetic Plastic Water Flow Sensor Switch G1/2
Suitable ambient temperature ≥1°C
Suitable working temperature ≤100°C
Minimum starting flow ≥ 0.75L/min
The maximum flow rate ≤5L/min
Rated working pressure ≤ 0.65Mpa
The maximum pressure of the shell ≤ 1.5Mpa
Signal output load DC24V/1A, AC36V/1A or AC220V/0.1A
SKU: SEN1562 -
Buzzers | Piezo | Speakers, Distance Measuring Sensors, Related Accessories, Sensors, Show All Accessories, Show All Gadgets, Tech Gadgets, Water Sensors
Mist Maker Ultrasonic Mist Creator Fogger Nebulizer Water Fountain Vaporizer
Buzzers | Piezo | Speakers, Distance Measuring Sensors, Related Accessories, Sensors, Show All Accessories, Show All Gadgets, Tech Gadgets, Water SensorsMist Maker Ultrasonic Mist Creator Fogger Nebulizer Water Fountain Vaporizer
Features:
With 12 LED colorful light.
No heat or chemicals used
Easy to operate, long service life, self-protection.
Ideal for indoor or outdoor fountains, water feature, and office use.
Add a stunning mist effect to your pond or water tank to filter the bad smell with electro and ultrasonic technology.
SKU: ACS4346 -
Sensors, Show All Sensors, Water Sensors
PH Electrode Sensor PH 0-14 Value Detection Monitoring Control Board Meter BNC PH Probe
Sensors, Show All Sensors, Water SensorsPH Electrode Sensor PH 0-14 Value Detection Monitoring Control Board Meter BNC PH Probe
Features:
Heating voltage: 5 plusmn 0.2V (AC middot DC)
Working current: 5-10mA
Detectable concentration range: PH0-14
Detection Temperature range: 0-80 ℃
Response time: le5S
Settling Time: le60S
Component Power: le0.5W
Working temperature: -10 ~ 50 ℃ (nominal temperature 20 ℃)
SKU: SEN1654 -
Sensors, Show All Sensors, Water Sensors
PH Electrode Sensor Prob PH 0-14 Meter BNC PH Probe
Features:
Heating voltage: 5 plusmn 0.2V (AC middot DC)
Working current: 5-10mA
Detectable concentration range: PH0-14
Detection Temperature range: 0-80 ℃
Response time: le5S
Settling Time: le60S
Component Power: le0.5W
Working temperature: -10 ~ 50 ℃ (nominal temperature 20 ℃)
SKU: SEN1655 -
Rain | Wind Sensors, Sensors, Show All Sensors, Water Sensors
Raindrops Detection Sensor Module for Arduino
Rain | Wind Sensors, Sensors, Show All Sensors, Water SensorsRaindrops Detection Sensor Module for Arduino
.3-5V Rain Raindrops Detection Sensor Weather Humidity Module For Arduino
Brand New
Feature:
1.The sensor USES the high quality FR – 04 double material, large area of 5.5 * 4.0CM, treatment of nickel plating and surface, have fight oxidation, electrical conductivity, and life has more superior performance;
2.With potentiometer sensitivity adjustment;
3.The output format: digital switch output (0 and 1) and analog AO voltage output;
4.Has a fixed bolt hole, convenient installation;
5.The comparator output, signal clean, good waveform, driving ability is strong, for more than 15 mA;
6.The LM393, use of wide voltage comparator;
SKU: SEN1509 -
Sensors, Show All Sensors, Turbidity Sensors, Water Sensors
Turbidity Sensor Suspended Turbidity Value Detection Kit
Sensors, Show All Sensors, Turbidity Sensors, Water SensorsTurbidity Sensor Suspended Turbidity Value Detection Kit
Turbidity sensors is the use of optics , through the liquid solution and scattering rate of transmittance integrated to determine the turbidity case , since the amount of haze value is gradual , usually detected in a dynamic environment , the turbidity sensor acquisition value , the need for external control for AD conversion , the conversion to obtain the corresponding environment turbidity situation, so that the sensor can also need to produce a peripheral circuit detected in the system , with a waterproof probe , mainly used in washing machines, dishwashers and other equipment turbidity testing can also be used on electronic design, graduate design, electronic competition experiments and other applications.
SKU: SEN1550 -
Sensors, Show All Sensors, Water Sensors
Turbidity Transducer Water Turbidity Module Mixed Water Detection Module 3.3-5V
Sensors, Show All Sensors, Water SensorsTurbidity Transducer Water Turbidity Module Mixed Water Detection Module 3.3-5V
Specification：
Ratio Range (NTU):0~1000±30
Infrared Emitting Diode:940nm
(Peak emission wavelength)
Photo Transistor:880nm
(Peak emission wavelength)
Vcc [V]:5
Operating Temp:-20~+90
Output Voltage[V]:0~5
Reverse Voltage[V]:5
SKU: SEN1590 -
Sensors, Show All Sensors, Water Flow Sensors, Water Sensors
Water Flow Sensor Flow meter 1/2″ 2.0MPa 1-30L-min
Sensors, Show All Sensors, Water Flow Sensors, Water SensorsWater Flow Sensor Flow meter 1/2″ 2.0MPa 1-30L-min
Features:
Mainly used for water testing, water cooling system
Application: Water heaters, credit card machines, water vending machine, flow measurement device
High amplitude: ≥ 4.6V
Low amplitude: ≤ 0.5V
Electric strength: 1250V/min
Insulation resistance: ≥ 100MΩ
Hydrostatic pressure testing: ≤ 2.0Mpa
Specification:
The lowest rated working voltage: DC4.5 5V-24V
SKU: SEN1530 -
Sensors, Show All Sensors, Water Level Sensors, Water Sensors
Water Level Sensor Detection Liquid Surface Depth Height
Sensors, Show All Sensors, Water Level Sensors, Water SensorsWater Level Sensor Detection Liquid Surface Depth Height
100% brand new and high quality
Size: 25mm×13mm/0.98″×0.51″(approx)
This module is based on principle of resistive voltage divider design,
can make the red terminal connector input voltage to 5 times smaller.Arduino analog input voltages up to 5 v,
the voltage detection module input voltage not greater than 5Vx5=25V
(if using 3.3V systems, input voltage not greater than 3.3Vx5=16.5V).
Arduino AVR chips have 10-bit AD, so this module simulates a resolution of 0.00489V (5V/1023),
so the minimum voltage of input voltage detection module is 0.00489Vx5=0.02445V.
Voltage input range : DC0-25 V
Voltage detection range : DC0.02445 V-25 V
Voltage analog resolution : 0.00489 V
Output Interface : “+ ” connected 5/3.3V, “-” connected GND, “s” connected Arduino AD pins
DC input interface : red terminal positive with VCC, negative with GND
By 3P connector, connect this module with the expansion of board Arduino,
SKU: SEN1525
